The Plasma-7 pickup is very responsive to the picking attack and allows for some of the best distortion available on this planet. Now if you want a pickup to play some jazz, this is not your pickup. If you want the world to hear your sound and then grab some gloves, install the Plasma-7 and let ‘er rip.
Plasma-7 pickups are carefully made with American made plain enamel copper wire; Ceramic bar type magnets. The coils are wax potted for stabilization to insure the complete, clean reproduction of sound.
Equipped with 4 wire leads that give the player endless tonal possibilities.
Black and White Available.
| PLASMA-7 | ||||
| Specification | ||||
| Position | Neck | Middle | Bridge | |
| D.C.Resistance | 7.5 Kohm | 9.5 Kohm | ||
| Resonant Peak | 7.3 kHz | 6.4 kHz | ||
| Spacing | 50 mm | 52.5 mm | ||
| Output level | Mid-High | High | ||
| Type | Dual Coil | |||
| Copper Wire | Plain Enamel | |||
| Magnet | Ceramic(Bar) | |||
| Tone Chart |  |
|||
| 4-Conductor Wire | Red-Hot | |||
| White & Black-Center | ||||
| Green & Shield-Ground | ||||
| Pickup Color | Black, White | |||
| Rock, Metal, Funk, Pop | ||||
